PBO Short Staple Fiber 1.7D~3.3D / 38mm、51mm、76mm

PBO, for poly(p-phenylene-2,6-benzobisoxazole) is a special material in fibres with high mechanical and thermal performance. PBO fiber is light-weight,flame resistant,high temperature resistant, and owns excellent strength and good wave transmittance, etc., with its comprehensive performance being the best of organic fiber. It could be widely used in aerospace, military equipment, fire protection and other applications apart from aramid fiber.

product details

PBO Staple Fiber

Take PBO filament as raw material,it was crimped,shaped, cutted by professional equipment. Feature of temperature resistant of 600 degree, with good spunability, cutting resistance, which widely used in fields of special technical fabric, fire rescue clothing, high temperature filter belt, heat restistant belt, aluminum and heat resistant shock absorbing material (glass processing).

specification

PBO staple fiber	Unit	Index
Fiber Contents	/	РВО
Density	dtex	1.7~3.3
Length	mm	38、51、76
Moisture regain	%	<4
Oil Length	%	0 ~ 2

Characteristics

High strength, high modulus, and creep resistamce

★ 450kg load-bearing capacity by only Imm fiber

★ Tensile strength:5.8 Gpa

★ Tensile modulus:160~280 Gpa

★ Outstanding dimensional stability at the wide-range temperature

High temperature resistamce

★ Decomposition temperature is 650℃

★ LOI:68%

★ Incombustible,no dripping

★ The best heat resistance organic fiber so far.It produces almost no toxic gas during decomposition process.

Low dielectric comstamt

★ Under the standard test conditions,its relative permitivity is 3.5 at a frequency of 10GHz.

Chemical stability

★ Little changes in intensity after 300h in organic solvent and alkali solutions

application

As a typical dual-use material with promising prospect,PBO fiber could be widely used in aerospace,national defense,fire-fighting equipment,rail transit,electronic communication,civil protection and other applications：

PBO staple fiber spun yarns can used as fireproof cloth for fire rescue clothing.

Spun yarn made by PBO fiber with steel fiber can weaving thermal resistant tape.

Thermal resistant filter made by PBO staple fiber felt etc.

PBO fiber can absorb a large amount of impact energy when impacted, which is an excellent impact resistant material. The maximum impact load of PBO fiber composite can reach 3.5KN and the energy absorption is 20J. The wear resistance of PBO is good, and the wear cycle is five thousand times.

PBO fiber at a high temperature of more than 300°C can reflect the better wear resistance properties, and its strength retention rate is about 45% after 100 hours of treatment in the air at 300°C.

PBO fabric lightly and flexiblility improved comfortability and mobility and it is ideally heat and fire resistant workwear material.
